Many fluid power systems fail simply because there is too much contamination in the medium.
Hydraulic filters keep the hydraulic fluid contaminant free. There are a several types of filters, including: Suction filters, return filters ,pressure filters,line filters.
| Model No. | Unit | ZU-H10 ~ ZU-H800 | QU-H10 ~ QU-H800 | |
|---|---|---|---|---|
| Flow rate | L/min | 10-800 | 10-800 | |
| Pressure | Mpa | 32 | ||
| Filtration accuracy | μm | 1,3,5,10,20,30 | ||
| Model of element | HX-10X ~ HX-800X | |||
| Weight | Kg | 3.6 ~ 52 | ||
The filter is installed on the pressure pipeline of the hydraulic system to quickly remove the mechanical impurities mixed in the hydraulic oil and the "colloid, bitumen quality, and similar quality inspections caused by the chemical change of the wave pressure oil itself, so as to prevent the valve core The occurrence of malfunctions such as jamming, cracks in the orifice, blockage of the orifice, and rapid wear of hydraulic components.
The filter has good filtering effect and high precision, but it is difficult to clean after clogging, and the core must be replaced.
The filter is equipped with a differential pressure signal device. When the filter element is blocked and the oil inlet and outlet pressure difference is 0.35MPa, the switch signal is sent out. At this time, the filter element is replaced to achieve the purpose of protecting the safety of the system.
The filter element of the source filter is made of glassy fiber filter material, which has the advantages of high sea-passing degree, large oil passing capacity, small original pressure loss and large dirt holding capacity. Its filtration accuracy is calibrated by absolute filtration accuracy, and the filtration ratio is β3, 5, 10. 20 > 200, filtration efficiency n≥995%, in line with IS0 standard.
Power plant
Petrochemical
Machine made
Traffic
Metallurgical Mine
